gof_residuals_time_boxplots

Description

plots boxplots of residuals over Nominal Times

Usage

gof_residuals_time_boxplots(
  data,
  fit,
  dv_col,
  conc_col,
  ntime_col,
  trt_col = NULL,
  residual_references = c(
  -2,
  2
),
  legend_location = c(
  "top",
  "bottom",
  "left",
  "right",
  "none"
),
  style = list(
)
)

Arguments

Name	Description
data	A dataframe of QTc dataset
fit	a deltaQTCF model fit
dv_col	an unquoted column name of deltaQTC/Dependent variable measurements
conc_col	an unquoted column name of concentration measurements
ntime_col	an unquoted column name of nominal times
trt_col	an unquoted column name of treatment group, default NULL will use for filling boxplots
residual_references	numeric vector of reference residual lines to add, default -2 and 2
legend_location	location of legend ggpubr::ggarrange argument
style	a named list of any argument that can be passed to style_plot

Returns

a plot

Examples

data_proc <- preprocess(data)
 fit <- fit_prespecified_model(
   data_proc,
   deltaQTCF,
   ID,
   CONC,
   deltaQTCFBL,
   TRTG,
   TAFD,
   "REML",
   TRUE
 )

 gof_residuals_time_boxplots(
   data_proc,
   fit,
   deltaQTCF,
   CONC,
   NTLD,
   TRTG,
   legend_location = "top")
