gof_residuals_plots

Description

Plots residuals vs predicted dQTCF and concentration

Usage

gof_residuals_plots(
  data,
  fit,
  dv_col,
  conc_col,
  ntime_col,
  trt_col = NULL,
  conc_xlabel = "Concentration (
  ng/mL
)",
  dv_label = bquote(
  Delta ~ "QTc (
  ms
)"
),
  residual_references = c(
  -2,
  2
),
  legend_location = c(
  "top",
  "bottom",
  "left",
  "right",
  "none"
),
  style = list(
)
)

Arguments

Name	Description
`data`	A dataframe of QTc dataset
`fit`	a deltaQTCF model fit
`dv_col`	an unquoted column name of deltaQTC/Dependent variable measurements
`conc_col`	an unquoted column name of concentration measurements
`ntime_col`	an unquoted column name of nominal times
`trt_col`	an unquoted column name of treatment group, default NULL
`conc_xlabel`	a string of concentration xlabel
`dv_label`	a string of dv label default bquote(Delta ~ ‘QTc (ms)‘)
`residual_references`	numeric vector of reference residual lines to add, default -2 and 2
`legend_location`	string for moving legend position.
`style`	a named list of any argument that can be passed to style_plot

Returns

a plot

Examples

data_proc <- preprocess(data)
 fit <- fit_prespecified_model(
   data_proc,
   deltaQTCF,
   ID,
   CONC,
   deltaQTCFBL,
   TRTG,
   TAFD,
   "REML",
   TRUE
 )
 gof_residuals_plots(
   data_proc,
   fit,
   deltaQTCF,
   CONC,
   NTLD,
   TRTG,
   legend_location = "top")
